Patriot 10:1 Adhesive System Operations Manual
Rev. 03/2014
Page | 34
Fluid Section Manual:
The Patriot 10:1 Adhesive system comes standard with two Patriot Chop Check Fluid
Sections (PAT-CCP-PA-1300-SS & PAT-CCP-PA-2300-SS). For a detailed description
of the repair procedures please see the following manual
For detailed repair instructions see the manual “Patriot Chop Check Manual PAT-
CCP-LS-0590
”
Metering Pump Manual:
The Patriot 10:1 Adhesive system comes standard with the Activator Metering Pump
(PAT-CP-1530-ADH). For a detailed description of the repair procedures please see
the following manual
For detailed repair instructions see the manual “Patriot Metering Pump Manual –
PAT-CP-1530”
