11
1
2
3
4
5
6
34.5"
44"
44"
45"
44.75"
41"
34.75"
36.5"
37"
37"
35.75"
39"
29.5"
32.5"
30.5"
30.5"
29.5"
27.5"
35"
42"
40"
37"
32"
28.5"
14"
14"
14"
14"
14"
14"
43"
32"
40"
43"
44"
41"
A B C D E
1
2
3
4
5
6
46"
46.75"
46.75"
47.25"
47"
42.5"
35.5"
35.5"
37"
37.25"
35"
33"
29.5"
33.5"
31.5"
30"
29.5"
26.5"
35"
42"
40"
37"
32"
28.5"
11"
11"
11"
11"
11"
11"
45"
37"
41"
45"
45"
41"
A B C D E DIST
ANCE
DIST
ANCE
INSTALLATION
» STANDARD INSTALLATION
Dimension ( A ) thru ( E ) are from the center of one pivot point to the center of another pivot point.
PROCEED TO PAGE 14.
POSITION THE GATE BRACKET
Gate Hinge Center
A
B
C
E
OUT
IN
Short Arm
Long Arm
Concrete Pad
OUT
IN
D
D MINUS 10"
10"
Wall
DISTANCE
If this dimension is
between 20 and 32
inches, a compact
installation is necessary.
Refer to following page.
SAMPLE STANDARD INSTALLATION IS SHOWN ON PREVIOUS PAGE.
Caution: If the gate is longer than 18 feet, follow CHART A: A-2 .
Suggestion: The dimensions between the gate and the concrete pad is always 10 inches less than the dimension D.
Example: D = 42", if the dimensions between the gate and the concrete pad is 32".
CHART A CHART B
