gENERAL SPECIFICATIONS
*Exclusive foot pedal release disengages gate from motor so it can be opened manually.
Maximum Gate Length 22 feet
Maximum Gate Weight 800 lbs
Cycles Continuous
Capacitors Aerovox 65µƒ, 240 V, 50/60 HZ, protected S 1000AFC
Application Commercial
Finish & Construction Gold/Zinc plated 3/16” H.R. Metal
Continuous duty Motor 1/2 Hp 120 Volts. AC 4.5 amp. 1625 rpm.
Power Failure Release Exclusive Foot Pedal Release
Overall dimensions H 22” - L 14½” - W 15”
Gate Travel Speed Approx. 1’ per sec
Shipping Weight 110 lbs
Do not exceed the specifications. The warranty on your unit will be void if
the installation exceeds the recommended specifications.
WARNING
