RAM 300

RAMSET

21

www.ramsetinc.com

BILL OF MATERIALS

ITEM

PART #

PART DESCRIPTION

QTY

76

800-75-41

TORQUE LIMITED ASSEMBLY

1

77

800-06-04

Sprocket - 40A40

1

78

800-26-01

Friction Disc, Torque Limited - 3 1/2"

2

79

800-26-10

Tension Washer, Torque Limited - 3"

1

80

800-34-22

Set Screw - 1/4" - 20 x 3/8"

2

81

800-36-20

Bolt, Hex Head - 3/8" - 16 x 1"

3

82

800-46-30

Bushing, UHMW Sprocket - ID 1 3/4" : OD 2"

1

83

800-58-02

Arbor Nut, Torque Limited

1

84

800-58-11

Arbor Washer, Torque Limited - 3 1/2"

2

85

800-58-31

Arbor, Torque Limited - 1"

1
