Ram 300, Bill of materials – Controlled Products Systems Group RAM300 User Manual
Page 21
RAM 300
RAMSET
19
www.ramsetinc.com
BILL OF MATERIALS
ITEM
PART #
PART DESCRIPTION
RAM 300
1
800-00-04
Chassis
1
2
800-02-04
Gear Reducer - Size 50, Ratio 80:1
1
3
800-04-10
Motor, Standard - 120VAC 1/2 HP
1
4
800-08-00
Pulley, Cast Iron - 5/8" x 10" (MA100)
1
5
800-08-45
Pulley, Cast Iron - 5/8" x 2" - AK20
1
6
800-10-06
Belt - 4L-380
1
7
800-12-00
Shaft - 1" x 13"
1
8
800-14-15
Cover, Polyethylene Cap Arm
1
9
800-20-05
Limit Switch
2
10
800-20-21
Switch, Foot Pedal
1
11
800-22-03
Spring - 1/4" x 1"
1
12
800-24-10
Foot Pedal Release
1
13
800-28-20
Square Pivot, 1 1/2" - 1"
1
14
800-28-40
Pivot Arm Release
1
15
800-44-01
Bearing, Flange - F205
2
16
800-48-05
Cam, Limit Switch - 1"
2
17
800-50-11
Wire Harness - Motor
1
18
800-50-41
Wire Harness - Outlet
1
19
800-50-90
Wire Harness - Foot Pedal
1
20
800-51-03
Wire Harness - Limit Switches
1
21
800-51-22
Wire Harness - Radio terminal
1
22
800-51-23
Wire Harness - xFMR to PCB
1
23
800-52-11
Chain, Drive - #40 - 28 1/2"
1
24
800-54-50
Bracket, Limit Switch
1
25
800-55-05
Bracket, Foot Pedal Guide
1
26
800-55-10
Bracket, Foot Pedal Switch/Lockdown
1
27
800-60-00
Transformer, 120/240V to 18VAC - 40VA UL
1
28
800-60-10
Switch, Rocker
1
29
800-62-00
Control Board - Intelligate
1
30
800-64-00
Edge Connector - 20 Pin
1
31
800-64-50
Radio Receiver Terminal
1
32
800-66-02
Lexan Control Board Cover
1
33
800-66-50
Lexan Limit Assembly Cover
1
34
800-68-04
Instruction Manual
1
35
800-70-20
Horn Alarm Buzzer
1
36
800-70-35
Knob - 5/16" - 18 x 1 1/2"
1
37
800-70-36
Knob - 5/16" - 18 x 1/2"
1
38
800-70-87
Snap Ring - 1"
1
39
800-70-98
Warning Sign For Gates - Slide/Swing
2
