44
REPAIR PARTS
NOT SHOWN
K94-36540 Wiring Harness with ID resistor assembly
K94-36250 Battery Harness (for 7AH batteries)
Q103 Swivel Arm Assembly
K80-36544 Vent Plug (for top gear box)
K80-36545 Vent Plug (for bottom gear box)
30 Amp Fuses
K74-30762 Two 7AH batteries
K94-36596 Battery Harness (for 33AH batteries)
ITEM PART NUMBER DESCRIPTION
1 K13-36117 Cludge Cover
2 K77-36538 Operator Cover with labels, keys, and lock
assembly
3 K73-36109 Chassis
4 K76-34644 APS Encoder with cable
5 K19-50038 #50 Drive Chain and Master Link
6 K32-35814 Gear Reducer (bottom)
7 K15-50B18LKGH Gear Reducer Sprocket with set screws and
key (1)
8 K77-36539 Output Shaft with sprocket, #35 limit chain,
and APS sprocket roll pin
9 K32-34655-1 Gear Box (top)
10 K10-36395 Battery Tray
11 29-NP712 Battery, 7AH, 12 Vdc
12 K204C0211 Toroid Transformer
13 K1A6408 APE Assembly with plastic tray, RPM board
with mounting hardware
14 K52C0481 Bridge Rectifier
15 K1D6597-1CC Main Board with heat sink
16 K1D6686CC Expansion Board
17 K76-34728 EMI Board with 120V receptacles and AC
power switch
18 K77-36541 Antenna
19 K76-36398 Motor, 1/2 HP, 24 Vdc
20 K77-36542 Electrical Box with junction box
21 K180A0357 Reset Switch
22 K94-35152 Alarm with harness
23 K75-36260 Lock and Keys
24 Q118 Keys
25 K13-34729 Dust Guard
26 Q061 Output Shaft Cludge Arm Clamp and Release
Handle
27 Q059 Output Arm
28 Q060 Release Handle
29 Q104 Standard Arm Assembly
INDIVIDUAL PARTS
