TROUBLESHOOTING
LCD Display References
LCD MSG Meaning
Page 35
TS Ref #s
Error Messages
ERR AC
LOW Indicates the AC line is low in voltage - AC voltage is below 90 VAC (or 180
VAC for 220 VAC operation).
1, 3, 4
ERR AC
HIGH Indicates the AC line is high in voltage - AC voltage is above 130 VAC (or
260 VAC for 220 VAC operation).
1, 3
ERR AC
NO AC
There is no AC voltage detected to the EMI Board from the 115/230 supply 1
ERR CHRG
HIGH
Potential problem with the charging voltage from the control board. 1, ?
ERR CHRG
CHECK 4A a) 4 Amp Fuse is blown
b) or there is a problem with the control board
18, ?
ERR BAT
LOW
The battery is low
1, 2, 3,
4
ERR FUSE
15 AMP
15 Amp motor fuse is blown 7, 11, 12
ERR EMI
NO EMI
No EMI board detected 15
ERR EMI
NO FUSE
4 Amp main fuse is blown on Power Supply Panel Assembly 2
ERR EMI
NO AC
There is no AC voltage detected from the EMI Board 20
ERR EMI
PROTECT
Lightning strike protection for the EMI Board has been damaged ?
