VIKING TECHNICAL SUPPORT 1.800.908.0884 3 3
TROUBLESHOOTING
LCD MSG Meaning
Page 35
TS Ref #s
Multi Meter Displays
MOT AMP
__._ A
This is the motor current amperage during operation
MOT VOLT
__._ VDC
This is the actual motor voltage during operation
AC VOLT
__._ VAC
This is the actual low voltage AC to the Control Board from the transformer
CHARGE
__._ VDC
This is the charging voltage to the batteries
BAT VOLT
__._ VDC This is the charging voltage when Battery Switch is OFF or the battery
voltage when the low voltage AC is discontinued to the Control Board
Board Settings Messages
Speed
xx% Shows the percentage of speed set by the Speed adjustment on the control
board. (pg. 18)
OVERLAP
_._ SEC Shows the number of seconds set by the Overlap Adjustment on the con-
trol board.
This feature is not available on slide gate operator models
ODS SENS
___% Shows the amount of force required to trip the obstruction sensor. (pg. 18,
20)
TIMER
__ SEC Shows the time delay to hold the gate open at the limit open position,
before starts closing the gate. (pg. 18)
HEATER
CLS OFF
The Integrated Heater has been disabled for the Closed Limit (pg. 21)
HEATER
CLS ON The Integrated Heater has been enabled to turn on at the Close Limit
position (pg. 21) “*” will be displayed while it is heating
HEATER
OPN OFF
The integrated Heater has been disabled for the Open Limit (pg. 21)
HEATER
OPN ON The Integrated Heater has been enabled to turn on at the Open Limit
position (pg. 21) “*” will be displayed while it is heating
LCD Display References
