1 2 3 4 5 6 7 8 -----------------------OPEN------------------------
TIMER
RADIO
OSC
FAIL SF/SC
1-PASS
SLAVE
AUTO OPEN
OPEN L/R
OFF ON
TIMER ON: Timer to close, can be set from 1 to 60 seconds.
TIMER OFF: Gate operation is push button to open, push button to close.
TO OVERRIDE THE TIMER: Turn the RADIO switch to the “ON” position.
This will allow the radio receiver to close the gate before the timer.
Turn potentiometer counter clockwise for more
time.
Turn potentiometer clockwise for less time.
RADIO “ ON ” = Allows
the transmitter to close
the gate before the timer.
TIMER “ ” to activate
the timer
ON
TIMER ADJUSTMENT
