RADIO RECEIVER CONNECTIONS
4 wire receiver: connect the two relay wires to & terminals. Black
wire to terminal and Red wire to terminal on
receiver strip outside control box as shown below.
1 2
negative 1 positive 3
3
2
1
3 = 12V
2 = Relay
1 = Common
Receiver terminal strip
located outside control
box.
4 wire 12VDC
Radio Receiver
