N.C. COM
THREE BUTTON STATION
SYSTEM
Connect the from all the push buttons
to input on the board.
Connect push button contact to
input on the board.
Connect push button contact to
input on the board.
Connect push button Contact to
input on the board and remove
jumper.
COMMON
COMMON
OPEN N.O.
EXIT
CLOSE N.O.
3BT
STOP N.C.
PED-SW
PED-SW
See push button connections below.
OPEN
CLOSE
STOP
A three button station was integrated
on the board to make adjustments
easier when setting limit switches
and adjusting ERDs.
N.O.
N.O.
PED-SW
Jumper
