Controlled Products Systems Group AOMSL100 - Manual (Page 7)

24”
16.25”
30”
7.5”
FOUR RED HEAD
BOLTS ½”X 3 ½”
Area for conduit(s)
GATE TRACK GATE
GATE TRACK
FOOTING
Minimum 5”
10”
8”
24”
4”
6”
When possible
Install 4” above
ground level
Footing for gate operator
Gate track
Footing
Drive chain level
CONCRETE PAD FOR SL-150
11
