Page 14: Normally closed contacts normally open contacts, Safety loop
1/4 IN
1/4 IN
1
1/2
IN
SAFETY LOOP
WHEN USED
EXIT LOOP
4F
T
4F
T
8F
T
8 FT
4F
T
4F
T
4F
T
GATE OPERATOR
GATE
GATE TRACK
TWISTED 6 TURNS
PER FOOT
WIRED IN SERIES
This is a normal loop layout. Remember when connecting to an All-O-Matic
circuit board you use the
for your safety loop
detector and
from the exit loop. You must twist
your wires from your exit point of the saw cut all the way to the circuit
board, no exceptions.
normally closed contacts
normally open contacts
OUT
SAFETY LOOP
NORMAL LOOP LAYOUT
25
