Controlled Products Systems Group 1603-080 - Manual (Page 39)

1603-065-N-7-11 37
460
VAC
230
VAC
White
Black/White
Brown
Black
Blue
To Blue
To White
White
Black/White
Brown
Black
Blue
To Blue
To White
230 / 460 VAC
NEU NEU HOT HOT HOT
AC Power UP/Auto/Down
Power
Neutral
Yellow
Purple
Blue
Blue Blue
Com
Red
Orange
Ground
Chassis Ground
Up Limit
Magnet
REVERSE
SENSITIVITY
TIME
DELAY
POWER
1 ON
2
3
4
5
6
7
8
1 ON
2
3
4
5
6
7
8
NC NO
UP
LOOP
DOWN
LOOP
1 2 3 4 5 6 7 8 9 10 11 12 13 14
1601
Current Sensor
Magnetic
Limit Sensor
1/2 HP 230 / 460 VAC
Step-Down
Transformer
Ground
1/2 HP
Single Phase
Down Limit Magnet (White Dot)
