Controlled Products Systems Group 1550ETL-1K User Manual

Page 2

background image

2

Table of contents

IMPORTANT SAFETY INSTRUCTIONS

…………………………………………………………...II

APPLICATION

….……………………………………………………………………………………… III

PRE-INSTALLATION CHECKLIST …………………………………...…………………..…….…..

IV

PART IDENTIFICATION ………………………………………...………………………………………..

V

Optional parts identification

1. OPERATOR INSTALLATION ………………………………………………………..…………

7

1.1 - Pivot Arm Installation (standard pull to open)

1.2

-

Actuator

Installation

1.3 - Control Box Installation

1.4 - Apollo 816-1K limit switch and smart sensor wiring

1.5 - Apollo actuator motor wiring and connection to the controller

1.6 - Actuator connection at the controller

1.7 - Gate Bracket Installation

1.8 - Limit Switch Adjustment

2. PUSH TO OPEN INSTALLATION …………………………………………………………...……..11

2.1 - PIVOT ARM(s) INSTALLATION

2.2 - REWIRING ACTUATOR TO PUSH OPEN

3. CIRCUIT BOARD LAYOUT ……………………………………………………………………....…

12

4. OUTPUTS & INPUTS ……………………..………………………………………………..…………

13

4.1 - Gate Operator Accessory Inputs

4.2

-

Communication

buses

4.2.1 - BLUEBUS ACCESSORIES

4.2.2 - Programming the plug-in receiver and remote controls

4.3.3

-

OVIEW

REMOTE

CONTROL

5. WIRING AND CONNECTIONS ………………………………...…………………………….……...…. 16
6. OPTIONAL INPUTS/OUTPUTS ……………………………………………………………..…..

17

6.1 - Fire dept. connection

6.2 - Exit and edge inputs wiring diagram

6.3

-

Guard

station

6.4 - Magnetic lock connection

6.5 - Radio receiver connection (third party)

7. INSPECTION AND OPERATION ………………………………………………………………….

18

8. GENERAL LAYOUT AND SAFETY ACCESS ………………………………………………....

19

9. ACCESSORIES AND SENSORS …………………………………………………………….……

20

10. BOARD DIAGRAM …………………………………………………………………….…………...

21

11. PROGRAMMING BUTTONS …………………………………………………………..…….………. 22

11.1 - Force

11.2

-

Speed

11.3 – Acceleration

11.4 - Delay

11.5

-

Function

11.6 – Display

12. GLOSSARY …………………………………………………………………………..………..……

28

13. EMERGENCY VEHICLE ACCESS …………………………………………………………….…… 28
14. MAINTENANCE SCHEDULE - APOLLO GATE OPENER

……………………………..….. 29

15. APOLLO GATE OPENER TROUBLESHOOTING ……………………………………………….... 29
16. APOLLO 816-1K PROGRAMMING QUICK START ………………..………………..………

30

17. PUTTING THE CONTROLLER INTO LEARNING MODE …………………..……….…….

30

18. INSTALLATION CHECKLIST …………………………………………………………….……

31

WARRANTY INFORMATION
