P a g e 1 9
Ja nua ry , 2 00 7
6 2 0 /6 40 O pera t or A nd
6 2 4B LD C ontr ol Pa ne l Ins talla tio n M a nual
POS PART
NUMBER
DESCRIPTION QTY
101 7221005 Spring Adjustment Fork 1
102 7182155 Shoulder Bolt 4
103 7049145 Spring Adj. Retainer 1
105 7360165 Cylinder Protection Guide 1
106 7222725 Spring Support Ring 1
107 2487 Snap Ring (Spring Support) 1
108 7039285 Washer 8
109 7110115 Banjo Bolt 4
110 N/A Lock Washer 2
111 2274 Screw (Air Bleed) 2
112 N/A Copper Washer 2
113 725202 Piston (Spring Side) 1
114 7073015 Ball Joint 2
115 N/A Harness (Thermal) 1
116 7543005 Temperature Switch 1
117 7361275 Hydraulic Hose 2
118 7039275 Fiber Washer 1
119 7099315 Gasket (Flange) 2
120 7112055 Oil Cap (Dip Stick) 1
121 7043355 O-Ring (Strain Relief) 1
122 N/A Strain Relief 1
123 N/A Screw 4
124 N/A Washer 4
125 7220625 Mounting Bracket 2
126 7099245 Gasket (Strain Relief) 1
127 7270535 Flange (Top) 1
128 2274 Vent Screw 1
129 7094065 Washer 1
130 7230295 Tie Rod 4
131 N/A Star Washer 4
132 N/A Operator Body 1
133 7514075 Power Cord 1
134 N/A Screw 1
135 2365 Bolt (Motor) 4
POS PART
NUMBER
DESCRIPTION QTY
136 N/A Washer 4
137 702003 Nut (Jam) 4
138* 7700205 Motor 1
139** 3204435 Lobe Pump* 1
140 N/A Fork (Non Spring Cylinder) 1
141 725203 Piston (Non Spring Side) 1
142 N/A Pin (Pump) 2
143 7090010015 O-Ring (Pump to Valve Body) 2
144 4404065 Inlet Valve 2
145 7049005 Retainer 2
146 7090300015 O-Ring (Shuttle Piston) 1
147 4180285 Shuttle Piston 1
148 4404085 Lock Valve 2
149 7049005 Retainer (Brass) 2
150 4997645 Valve Body 1
151 N/A Roll Pin (Manual Release Lock) 1
152 N/A Bolt (Allen Head) 2
153 N/A By Pass Valve Feet 2
154 N/A By Pass Valve Spring 2
155 4180395 By Pass Screw 1
156 4180395 By Pass Screw 1
157 7090150015 O-Ring ( By Pass Screws) 2
158 N/A O-Ring (Manual Release) 1
159 4180305 Manual Release 1
160 7090050015 O-Ring (Inlet Valve) 6
161 N/A Roll Pin (Manual Release Rod) 1
162 N/A Coupler (Manual Release Rod) 1
163 7128035 Manual Release Knob
(Triangular)
1
164 424593 Manual Release Assembly 1
165 N/A Wiper Seal 2
166 N/A O-Rings (Cylinder Top) 2
167 7090360025 O-Ring (Piston Center) 2
168 N/A O-Ring (Cylinder Center) 2
169 6115* Artic Grade Oil (Quarts) 2
170 2170* Seal Kit 1
