Pag e 16
Jul y , 2 00 6
3 9 0 24 v O pe ra t or And
4 2 5 D C ontrol Pa ne l I nsta ll a ti on Ma nua l
A CTIVATING D EVICES AND R ADIO R ECEIVER : The
activating devices and radio receiver for your gate
must have normally open (N.O.) contacts. Connect
such devices to terminals OPEN A and COM.
N OTE : The FAAC radio receiver plugs into
the 5 prongs labeled CN5 (Quick connect
port).
Page 19 shows how to connect a three or four wire
receiver.
FAAC PLUG IN RADIO RECIEVER: If you are
installing the FAAC Receiver use the quick-fit
connector CN5.
N OTE : If your using both a receiver and
decoder, hard wire the decoder and plug in
the receiver.
O PEN /H OLD O PEN D EVICE : To open and hold open
the gate, simply maintain a contact across terminals
OPEN A and COM. (“A” Mode only)
S TOP B UTTON : The stop button you install must
have normally closed (N.C.) contacts. Multiple stop
buttons must be wired in series. Connect your stop
device between terminals STOP and COM.
N OTE : The 425 D will not operate the motors
without a closed circuit between STOP & COM.
The LED Indicators: The nine light emitting
diodes (LEDs) on the control panel can be used to
check for the proper function of the devices
attached to the panel. The LED lights are on
whenever the contacts are closed across each of the
respective terminals.
LED On Off
DL1 Power On Power Off
DL7
FSW CL Closing
Safeties Normal
Closing
Safeties
Triggered
DL8
FSW OP Opening
Safeties Normal
Opening
Safeties
Triggered
DL3
STOP Stop Device
Normal
Stop Signal
Given
DL2,DL3
DL4,DL5
Limits
Limit Switches
Normal
Limit Switches
Triggered
T
HE
425 D C
ONT
R
OL
P
ANE
L
I
NSTALLA
T
ION
I
NS
TRUCTIONS
OP_A and OP_B (Partial Opening) should illuminate only
when an activating signal is sent for 2 and 1 gate leaves,
respectively. STOP should be illuminated except when
the stop button is pressed. FSWOP and FSWCL should be
illuminated except when the reversing devices, for
opening and closing, respectively, are triggered. Use the
LEDs and the next table to determine if the accessory
devices you have installed are operating properly.
Electric Locks: An electric lock can be wired to the
425 D in
terminals ELS and ELS (24Vdc pulsed
provided). If a reversing stroke is needed to allow the
electric lock to release, this must be done in
programming.
See page 19 for the connections for a magnetic locking
device.
W ARNING L IGHT : Connect a warning light to
terminals labeled lamp in the CN2 terminal block.
The terminals provide an output voltage of 24 VDC,
maximum power 15 Watts. This output voltage will
power most 24 VDC warning lights.
N OTE : The behavior of the warning light is as
follows. During programming the light will flash
every 1/2 second during opening and every 1 1/2
seconds during closing. If you are in automatic
mode (A), upon reaching the open position, the
output will remain on for 5 seconds to inform you
that the gate will close automatically. It will also
flash for up to 10 seconds if the gate is open and a
safety is triggered.
The output can also be set as a courtesy light that stays
illuminated for 90 seconds. See the programming
section (G0 and G1) for further details
S
ET
O
THER
O
PERATING
C
ONTROLS
WARNING
! Turn the main power off before you
make any electrical connections.
You need to program the control panel for your gate's
operation. The 425 D Control Panel has on board
programming that controls a wide range of functions.
O PERATING L OGICS
N OTE : The 425 D Control Panel provides inputs
for opening reversing devices and closing
reversing devices. FAAC strongly recommends
the use of reversing devices, such as photocells
or other non-contact sensors.
• A (automatic): The gate opens on command
and automatically closes after a pause phase. A
second command while opening is ignored; a
second command during the pause phase
interrupts the pause time; a second command
