T
HE
425 D C
ONTROL
P
ANEL
G
ENERAL
D
ESCRIPTION
The FAAC 425 D control panel is used to operate the
following models.
Swing gate operators:
415 412
390 770
The 425 D programming controls the following:
Operating logic: A, EP, logics available.
Pause time between opening and closing: Done
during the motor programming time.
Opening/Closing time: Self Learning. (During the
programming stage
Leaf delay on closing: adjustable from 1.5 to 10
seconds.
Leaf delay on opening: 1.5
The 425 D control panel should be installed in an
enclosure that is conveniently located as close as
possible to the gate operator. All electrical
connections from the control panel to the operator
must be made in a weatherproof junction box.
The 425 D control panel requires the 100VA
transformer (included) 115vac primary and 24vac
secondary. The power supply should be protected by
a 15 amp dedicated circuit breaker (not provided).
The installer is responsible for providing the main
power breaker switch, and for making sure that the
entire gate system meets all applicable electrical
codes. The installer should refer to the installation
manual for a given operator for more information.
N OTE : An installation is U.L. compliant only
when you install the FAAC operators
according to the UL325 standards.
I
NSTALLING THE
425 D C
ONTROL
P
ANEL
Installing the control panel consists of the following
general steps:
∗ Connecting the main power to the control
panel
∗ Connecting the activating device
∗ Connecting the operator to the control panel
∗ Checking the direction of the motor's rotation
∗ Connecting other devices to the control panel
∗ Set operating modes
C
ONNECT THE
M
AIN
P
OWER
S
UPPLY
WARNING! Turn the main power off before you
make any electrical connections or before
programming.
The main power can be provided in a variety of
different ways.
1) Bring a 115VAC line into the enclosure and wire
to the terminals provided, and plug the
transformer into the outlet provided inside the
enclosure.
2) Plug the transformer into any 115VAC outlet and
bring the low voltage (24VAC) wires into the
enclosure wiring them directly to the control
panel as described below. Be sure to use the
appropriate size wire for longer runs.
C
ONNECT THE
O
PERATOR
(
S
)
TO THE
C
ONTROL
P
ANEL
WARNING!
Turn the main power off before you
make any electrical connections.
U SING A J UNCTION B OX
If an operator is more than 2 ft away from the control
panel, you must use a junction box for connection. Use
a U. L. Listed cord grip where the operator cord enters
the junction box.
Note: If you have a one-leaf gate design, the
operator must be connected to Motor 1 (terminals
APM1 and CHM1) in the CN2 Terminal Block
To wire up motor 1, connect the blue wire to terminal
APM1(on the CN2 terminal strip), the brown wire to
CHM1..
Note: If you want to delay the closing of one gate
leaf in a two-leaf gate design, be sure to connect
its operator to Motor 1.
In order to wire motor 2 in a bi-parting system, connect
the blue wire to terminal APM2 (on the CN2 terminal
strip), the brown wire to CHM2.
