3 9 0 24 v O pe ra t or A nd
4 2 5 D C ontrol Pa ne l I nsta ll a ti on Ma nua l
Parts List
390 24v Operator
POS PART NO.
DESCRIPTION
QTY
2
N/A
Operator body
1
5
727292
Protective Cover
1
6
N/A
Manual Release Assembly (Inner)
1
7
N/A
Gear (Upper)
1
8
N/A
Gear (Lower)
1
10 713001
Key (Manual Release Lever)
1
11 718189
Gear (Main Drive Shaft)
1
12 N/A
Bushing Brass (Upper)
1
13 N/A
Manual Release (Outer)
1
14 722471
Mounting Frame
1
15 N/A
Bushing Brass (Bottom)
1
16 N/A
Fender Washer
1
17 N/A
Motor 24VDC
1
20 N/A
Motor Housing 24VDC
1
21 N/A
Snap Ring
1
22 N/A
Seal (Lower)
1
23 6202
Bearing (Sealed)
4
24 6206
Bearing (Sealed)
2
25 N/A
Nut (8mm x 1.25mm x 6.5mm)
1
26 N/A
Spacer
1
27 N/A
O-Ring (2.62mm x 61.60mm)
1
28 N/A
Washer (8mm x 2mm)
1
29 N/A
Snap Ring
1
30 N/A
Snap Ring
1
31 N/A
“C” Clip
1
32 N/A
Screw Self Tapping (3.5mm x 9.5mm)
3
33 N/A
Bolt (8mm x 110mm)
2
34 N/A
Bolt (5mm x 16mm)
3
35 N/A
Screw Cap (6mm x 70mm)
3
36 N/A
Screw (4mm x 10mm)
3
