CNB NXE3055VR - Manual (Page 46)

XNET User Manual
46 / 54
View
Load saved
images
Load Saved images through internal FTP Server.
Port Configure internal FTP Server Port between 1 and 65535.
Save - Applies and saves the configurations.
Reset - Recalls previously the saved configurations.
The saving of SD Card will remove the past captured Image or Movie files about total
20% of SD Memory Card when exceed over 94% of SD Memory Card for occurring event.
In case of SD Card, It support MAX 32G and recommend over Class 4.
e.g. 1080p, 4Mbps, 30fps, H.264, Pre 2 seconds + Post 3 seconds :
It will save about 750MB hourly when use SD Card 16G Class 6.
Event can be ignored about occurred event during SD Memory Card save high size of
Image or Movie files.
Also, FTP & SMTP can be missed the occurred events next time when Network is
unstable.
e.g. High size of Image or Movie? High Resolution, High Bitrate, etc…
