XNET User Manual
45 / 54
ITEM DESCRIPTION
Event
Enable
Enable Event Enable / Disable event processing.
Event Mode
Sensor Enable / Disable the Alarm Sensor.
Motion
Detection
Enable / Disable Motion Detection.
Network
Linkdown
Enable / Disable Network Linkdown.
Please use after『Save image to SD Memory』enabled.
Alarm output
port
This sends out Alarm signal to its output port during event
processing.
Event
Settings
Capture
Stream
Select saved stream when processing an event.
When Dual-Codec enabled, you can select Dual Stream.
When Triple-Codec enabled, you can select Triple Stream.
Capture
Format
Display stream format of selected Capture Stream.
Capture
Frame
(MJPEG)
Configure saved frame among 1 / 2 / 3 when processing an
event.
Pre-Alarm
When processing an event, this establishes saving images or
video before the occurrence of the event.
It can be saved MAX 5 seconds before the event.
Post-Alarm
When processing an event, this establishes saving images or
video after the occurrence of the event.
It can be saved MAX 8 seconds before the event.
Event
Output
Upload image
to FTP
This allows Alarm images or video to be uploaded to an FTP
server when processing an event.
The client PC has to run FTP server to receive the images or
videos, and the information of the FTP server has to be
accurately entered and saved at the FTP Configuration page.
Send Image
to Email
This allows Alarm images (Not Video) and time information
message When processing an event.
Only on images file at the moment of the event gets the
image out via e-mail.
The e-mail address has to be accurately entered and saved
at SMTP configuration page.
Save image
to SD
Memory
This allows Alarm images to be saved to SD card when
processing an event.
This flag must be sure to check “disable” state when SD
Memory card remove.
