XNET User Manual
23 / 54
ITEM DESCRIPTION
Main Stream
(H.264)
Resolution
Select a resolution of main stream video.
[QVGA | CIF | VGA | D1 | XGA | 720P | SXGA (1280x960) | SXGA
(1280 x 1024) | 1080P]
Enable
Dual-Codec
Turns Dual Stream feature on or off.
Dual Stream output is in H.264 & MJPEG Codec.
When configuring, select Main or Dual Stream in the Live View page.
Enable Triple-
Codec
Turns Triple Stream feature on or off.
Triple Stream output is in H.264 & MJPEG Codec.
When configuring, select Main/ Dual/Triple Stream in the Live View
page.
Frame rate
Selects Frame rate of Video.
[NTSC : 1 ~ 30 fps]
[PAL : 1 ~ 25 fps]
Bit Control
Select Bitrate mode.
[CBR / VBR]
Bit rate
(CBR)
Select CBR bitrate between 64kbps and 10Mbps depending on Main
Stream’s resolution.
Bit rate : Max
(VBR)
Select VBR max bitrate between 64kbps and 10Mbps depending on
Main Stream’s resolution.
Dual Stream
(H.264 / MJPEG)
Codec
Select Video Codec.
[H.264 | MJPEG]
Resolution
Select a resolution of dual stream video among QVGA | CIF | VGA |
D1 | XGA | 720P depending on Main Stream’s resolution.
Frame rate
Select Frame rate of Video.
[NTSC : 1 ~ 30 fps]
[PAL : 1 ~ 25 fps]
Bit Control
(H.264)
Select Bitrate mode.
[CBR / VBR]
Bit rate
(H.264 &
CBR)
Select CBR bitrate between 64kbps and 5Mbps depending on Dual
Stream’s resolution.
Bit rate : Max
(H.264 &
VBR)
Select VBR max bitrate between 64kbps and 5Mbps depending on
Dual Stream’s resolution.
Quality
(MJPEG)
Select MJPEG’s video quality between 10 and 100.
