XNET User Manual
10 / 54
ITEM DESCRIPTION
Capture -
Captures the still image and displays on a pop-up window.
[Save to] c:₩xNetCapture
Setting -
Opens up Basic setup Page.
Setup page for each XNET function can be opened from this Menu
screen.
(Please refer to [1.4. Status Window] for detail.)
Live View -
Opens up Live index View Page.
Index View Page will display Video as well as setting up Stream
Protocol and Service.
Stream Protocol -
A Stream Protocol can be selected when selecting Edit Box.
[RTP over UDP / RTP over TCP / RTP over HTTP /
RTP Multicast]
Triple Stream
Service
Main Stream When this box is checked, Main Stream Video is displayed.
Dual Stream
When this box is checked, Dual Stream Video is displayed.
(H.264/MJPEG) Dual-Codec needs to be enabled in Video Setup Page
in order to enable for Dual Stream Video to be displayed.
(Please refer to [1.10. Configuring Video] for detail.)
Triple Stream
When this box is checked, Triple Stream Video is displayed.
(H.264/MJPEG) Dual-Codec needs to be enabled in Video Setup Page
in order to enable for Triple Stream Video to be displayed.
(Please refer to [1.10. Configuring Video] for detail.)
