Sensor Status LED: Green (On when sensor closed, Off when sensor open)
Set Button: Toggles output relay On/Off. Also used for setup.
Momentary Duration: Adjustable, 2 - 105 minutes
Operation Modes: INSTEON only, X10 only, INSTEON and X10 Combo Mode
Combo mode Message Order: INSTEON, INSTEON confirmation, X10
Multi-Way Circuit Support: Yes
Setup Memory: Non-volatile EEPROM
INSTEON Features
INSTEON Addresses: 1 hard-coded out of 16,777,216 possible
INSTEON Links: 417
INSTEON Powerline Frequency: 131.65 KHz
INSTEON Minimum Transmit Level: 3.2 Vpp into 5 Ohms
INSTEON Minimum Receive Level: 10 mV
INSTEON Messages Repeated: Yes
Mechanical
I/O Terminals: 5V (10mA), GND, Sense, N/C, N/O, Common (28-16 gauge wire)
Input jack: 1/8" mini jack input (GND, Sense)
Input Type: Contact closure only
Output Relay Capacity: 5A @ 30 Volts (AC or DC)
Operating Conditions: Indoors, 32 to 104°, up to 85% relative humidity
Dimensions: 4.5" H x 2.5" W x 1.5" D
Weight: 4.6 oz
Electrical
Supply Voltage: 120 Volts AC +/- 10%, 60 Hertz, single phase
Sensor Input: 1/8" mini jack input (GND, Sense)
Power Plug : 3-pin grounded
Pass-through Outlet: Uncontrolled 3-prong (with ground), 120V, 15A
Power Consumption: 0.93 Watts
Certification: Safety tested for use in USA and Canada
X10 Features
X10 Primary Address: Two optional (comes unassigned). One for input, one for output
Certification And Warranty
Certification
This product has been thoroughly tested by ITS ETL SEMKO, a nationally recognized independent third-party testing laboratory. The North American ETL Listed mark
signifies that the device has been tested to and has met the requirements of a widely recognized consensus of U.S. and Canadian device safety standards, that the
manufacturing site has been audited, and that the manufacturer has agreed to a program of quarterly factory follow-up inspections to verify continued conformance.
Limited Warranty
Seller warrants to the original consumer purchaser of this product that, for a period of two years from the date of purchase, this product will be free from defects in
material and workmanship and will perform in substantial conformity to the description of the product in this Owner’s Manual. This warranty shall not apply to defects or
