Page 16 of 19 2478D - Rev: 1/21/2014 7:32 AM
After a few seconds, SwitchLinc will (Beep)-(Beep)
SwitchLinc will turn load on full bright
Specifications
General
Product Name
SwitchLinc Dimmer - INSTEON Remote Control Dimmer 100 -
277VAC 50/60Hz (Dual-Band)
Brand Smarthome
Manufacturer Product Number 2478D (White)
UPC 2478D: 813922012231
FCC ID SBP2477D
Patent Number 7,345,998 US, International Patents Granted and Pending
Warranty 2 Years, Limited
INSTEON
INSTEON ID 1
INSTEON 400 responder groups & 1 controller group
Maximum Scene Memberships 400 (Combined Controller + Responder)
Brightness Levels 32 (256 with software)
Scene Commands Supported as
Controller
On Off
Press & Hold Bright Press & Hold Dim
Fast On Fast Off
Scene Commands Supported as
Responder
On Off
Press & Hold Bright Press & Hold Dim
Incremental Bright Incremental Dim
Fast On Fast Off
Software Configurable Yes, Always
RF Range 100’ Open air
X10 Support Yes
INSTEON Device Category 0x01 Dimmable Lighting Control
INSTEON Device Subcategory 0x31
Mechanical
Mounting Standard, single gang wall box
Wires 3, 16 gauge, 1 stranded copper wire
Wires
Black - Hot
White - Neutral
Red - Load
Bare Copper - Ground
