44
Sampler operation
4.2.2 Navigation
Use the controller to access all sampler operations. Use the
ARROW keys, ENTER key and BACK key to move from one screen
to another. An arrow on the display indicates that more screens are
available (
Figure 25 ).
Example:
1. Press the MAIN MENU key.
2. Press the DOWN ARROW key to highlight diagnostics.
Press ENTER . The diagnostics menu will be shown.
3. Note the down arrow on the bottom of the display ( Figure 25 ).
Press the down arrow until additional options are shown.
4. Press the BACK key or MAIN MENU key to return to the
main menu.
4.2.3 Parameter selection
Parameter selection is made in one of two ways ( Figure 26 ):
• Selection from a list
• Enter a value using the arrow keys
Figure 25 Screen navigation
1 Left arrow 3 Up arrow
2 Right arrow 4 Down arrow
Figure 26 Parameter selection
1 Select item from list 2 Enter value with arrows 3 Acceptable range
