25
Installation
3.3 Sampler preparation
CAUTION
Biological sample hazard. Follow safe handling protocols
during contact with sample bottles and sampler components.
Disconnect the sampler from power to disable the pump
before handling.
The sampler is set up at the factory with a single bottle or multiple
bottle configuration. To change the bottle configuration:
• Use Figure 3 on page 11 or Figure 4 on page 12 to determine
the components that are required for the selected
configuration.
• Install the full bottle shut-off device ( section 3.3.2.1 on page 26 )
or distributor assembly ( section 3.3.3.4 on page 34 ).
3.3.1 Clean the sample bottles
Clean the sample bottles and caps using a brush and water with a
mild detergent before setting up the sampler. Rinse the containers
with fresh water followed by a distilled water rinse. Glass bottles
may also be autoclaved.
Figure 9 AWRS Anchor bracket locations with mounting dimensions
1 Anchor brackets (2x) 2 Optional anchor brackets
