Page 34: Download the viewer, Om the, Ipeps itself, If you have been asked to also enter a port number
If you need to enter a port number
Usually, when you make a network connection to the iPEPS (either using the
VNC viewer or a Web browser) you simply enter the IP address, i.e. 192.168.0.3.
However, if a special configuration is necessary, then you may be asked to
specify a port number as well as the IP address.
To enter a port number in a Web browser
1 Enter the required IP address in the usual Address box,
i.e. http://192.168.0.3
2 At the end of the IP address, add a single colon and then enter the port
number (in this example, the required port number is 8000),
i.e. http://192.168.0.3:8000
3 Continue with the standard
To enter a port number in VNC viewer
1 Enter the required IP address in the usual ‘Server’ box,
i.e. http://192.168.0.3
2 At the end of the IP address, add two colons and then enter the port
number (in this example, the required port number is 11590),
i.e. http://192.168.0.3::11590
3 Continue with the standard
Downloading VNC viewer from the iPEPS
The iPEPS has the ability to distribute its own VNC viewer application.
To download the VNC viewer
1 Open your Web browser.
2 Enter the network address where the iPEPS is situated (in the form:
http://192.168.0.3) and make the link.
3 In the opening iPEPS screen, click the link that offers to download the secure
VNC viewer ‘from the unit’.
4 Save the download file (vncviewer.exe) to your system.
5 Select and run the downloaded file and then connect to the iPEPS using the
.
