19 IOM-988/989-BODY
ITEM NO. DESCRIPTION
1 Body
2 Bonnet
3 Plug & Stem Assembly
4 Packing Flange
5 Packing Follower
6 Packing
7 Packing Washer
8 Guide Bushing
9 Packing Spacer
10 Cage
11 Seat Ring (Metal or
Soft Seat)
12 Bonnet Gasket
ITEM NO. DESCRIPTION
13 Gasket (Seat Ring)
14 Stud (Packing Flange)
15 Hex. Nut (Packing
Flange)
16 Bonnet Stud
17 Stud Nut
19 Flange (Body 150# or
300#)
20 Split Ring
21 Packing Spring
22 Wiper Ring
23 Seat Retainer (Soft Seat)
ITEM NO. DESCRIPTION
24 Seat Insert (Soft Seat)
25 Yoke Nut
26 Follower Bushing
42 Bushing
48 Screw (Split Rings)
51 Indicating Washer
52 Stem Nuts
MODEL 988/989 BODY ASSEMBLY (BA)
Internal Live Loaded Packing — Metal Seated Design
ITEMS NOT SHOWN DESCRIPTION
31 Pipe Plug (-26 Leak
Off Connection)
53 Bonnet Spacer (2" Size)
Composition Soft
Seated Design
