Calibration Parameters Verification
The instrument uses a set of predetermined calibration parameters to process flow signals. Most of these parameters should not
change. A data package located with this manual contains the “ST50 Delta R Data Sheet”. This contains the calibration parameters
stored in the flow transmitter at the factory. To verify that these parameters have not changed, complete the following:
1. Identify the appropriate Delta R Data sheets by serial number of the instrument.
2. Press [D] [ENTER] to examine each of the parameters. The [ENTER] key allows scrolling one message at a time. Use
Table 4 to verify parameters with the Delta R Data sheet ST50 Parameters.
Table 4. Diagnostic Test Sequence on Display
S/W Vers ion:
dR M in:
T SpanIDAC 0:
Flow Factor:
dR M ax:
T ZeroIDAC 0:
Cmin Flow:
Cal Ref:
T SpanIDAC 1:
Cmax Flow:
Tcs lp:
T ZeroIDAC 1:
Eng Units :
Tcs lp 0:
State 0:
Line Size 0:
Tcs lp 2:
Switch Pt 0:
Line Size 1:
Tot M enu:
State 1:
Cmin Temp:
Tot Flag:
Switch Pt 1:
Cmax Temp:
Totalizer:
K factor 1:
M in Flow:
Rollover Cnt:
K factor 2:
M ax Flow:
Fix Pt Flag:
K factor 3:
Dens ity:
Pulse Factor:
K factor 4:
*C1 [1]:
Pulse Out:
I factor:
*C1 [2]:
Hours:
Temp Flag:
*C1 [3]:
Sample Period:
Out M ode:
*C1 [4]:
dR Slope:
Boxcar M ax:
*C1 [5]:
dr Off Set:
RTD-SLP-385:
Break Pt:
Refr Slope:
% of Range:
*C2 [1]:
Refr Off Set:
User Name:
*C2 [2]:
SpanIDA C 0:
Shop Order #:
*C2 [3]:
ZeroIDA C 0:
Serial No.:
*C2 [4]:
SpanIDA C 1:
M odel#:
*C2 [5]:
ZeroIDA C 1:
LCD M ultiplier
If parameters that have an asterisk (*) have changed, this may indicate a problem. Customer Service should be contacted. If the
parameters have not changed, continue with the next section.
