ST100 Series Foundation Fieldbus
Fluid Components International LLC 15
ST100 Flow Analog Input Block
The table below summarizes the ST100 Flow Analog Input Block.
INDEX PARAMETER DATA TYPE (LENGTH) INITIAL VALUE DESCRIPTION
1 ST_REV Unsigned 16 0
2 TAG_DESC OctString(32) Spaces
3 STRATEGY Unsigned 16 0
4 ALERT_KEY Unsigned 8 0
5 MODE_BLK DS-69 O/S
6 BLOCK_ERR Bitstring(2)
7 PV DS-65 ST100 FLOW value from the transducer
block
8 OUT DS-65 ST100 FLOW value available to other
function blocks.
9 SIMULATE DS-82 Disable
10 XD_SCALE DS-68 0 - 100%
11 OUT_SCALE DS-68 0 - 100%
12 GRANT_DENY DS-70 0
13 IO_OPTS Bitstring(2) 0
15 CHANNEL Unsigned16 0 The Channel needs to be set to "Flow
average"
16 L_TYPE Unsigned 8 0
17 LOW_CUT Float 0
18 PV_FTIME Float 0
19 FIELD_VAL DS-65
20 UPDATE_EVT DS-73
21 BLOCK_ALM DS-72
22 ALARM_SUM DS-74
23 ACK_OPTION Bitstring(2)
24 ALARM_HYS Float
25 HI_HI_PRI Unsigned 8
26 H_HI_LIM Float
27 HI_PRI Unsigned 8
28 HI_LIM Float
29 LO_PRI Unsigned 8
30 LO_LIM Float
31 LO_LO_PRI Unsigned 8
32 LO_LO_LIM Float
33 HI_HI_ALM DS-71
34 HI_ALM DS-71
35 LO_ALM DS-71
36 LO_LO_ALM DS-71
