ST100 Series Foundation Fieldbus
14
Fluid Components International LLC
FACTORY SETTINGS
INDEX
PARAMETER
DATA TYPE (LENGTH)
INITIAL VALUE
DESCRIPTION
51
PRESSURE VALUE SENSOR #13
Floating Point
0
52
FLOW VALUE SENSOR #14
Floating Point
0
53
TEMPERATURE VALUE SENSOR #14
Floating Point
0
54
PRESSURE VALUE SENSOR #14
Floating Point
0
55
FLOW VALUE SENSOR #15
Floating Point
0
56
TEMPERATURE VALUE SENSOR #15
Floating Point
0
57
PRESSURE VALUE SENSOR #15
Floating Point
0
58
FLOW VALUE SENSOR #16
Floating Point
0
59
TEMPERATURE VALUE SENSOR #16
Floating Point
0
60
PRESSURE VALUE SENSOR #16
Floating Point
0
61
MAX CAL FLOW
Floating Point
0
62
MIN CAL FLOW
Floating Point
0
63
MAX CAL TEMP
Floating Point
0
64
MIN CAL TEMP
Floating Point
0
65
MAX CAL PRESS
Floating Point
0
66
MIN CAL PRESS
Floating Point
0
67
FLOW_ENG_UNITS
Unsigned16
0
68
PLENUM_ENG_UNITS
Unsigned16
0
69
TEMP_ENG_UNITS
Unsigned16
0
70
PRESSURE_ENG_UNITS
Unsigned16
0
71
TOTALIZER_ENG_UNITS
Unsigned16
0
72
PLENUM_SIZE_VALUE_DIAMETER
Floating Point
0
73
PLENUM_SIZE_UNITS_HEIGHT
Floating Point
0
74
FACTORY RESTORE
Unsigned8
0
Flow Analog Input Block
This block takes the input data from the Process Data Transducer Block, selected by the “Flow Average Channel” and makes it available to other
function blocks at its output.
L_TYPE parameter
This parameter determines how the values passed by the Process Transducer Block will be used in the block. There are two options; direct or
indirect.
Direct
The Process Data Transducer flow value is passed directly to the PV of this AI block, and the XD_SCALE information is not used.
Indirect
The Process Data Transducer flow value is converted to the OUT_SCALE and the information of XD_SCALE is applied.
CHANNEL parameter
This parameter selects the process variable to be used. The CHANNEL parameter, in the ST100 for the Flow Analog Input Block MUST be set
to “Flow Average”.
XD_SCALE parameter
This parameter sets the high and low scale values, the units index, and the number of digits after the decimal point, for display purposes.
