ST100 Series HART
Fluid Components International LLC 17
HART COMM NUMB. HART COMMAND DESCRIPTION HART DATA TYPE & SIZE
160
WRITE (4-20mA) OUTPUT CHANNEL #1 PARAMETERS
D/A SETTING FOR 4mA OUT
OUTZ1
UNSIGN (2BYTES)
D/A SETTING FOR 20mA OUT OUTF1
UNSIGN (2BYTES)
CHANNEL #1 OUT VARIABLE CHA_1_PRO_VAR
UNSIGN (1 BYTE)
161
READ (4-20mA) OUTPUT CHANNEL #1 PARAMETERS
D/A SETTING FOR 4mA OUT OUTZ1
UNSIGN (2BYTES)
D/A SETTING FOR 20mA OUT OUTF1
UNSIGN (2BYTES)
CHANNEL #1 OUT VARIABLE CHA_1_PRO_VAR
UNSIGN (1 BYTE)
163
WRITE (4-20mA) OUTPUT CHANNEL #2 PARAMETERS
D/A SETTING FOR 4mA OUT
OUTZ2
UNSIGN (2BYTES)
D/A SETTING FOR 20mA OUT OUTF2
UNSIGN (2BYTES)
CHANNEL #2 OUT VARIABLE CHA_2_PRO_VAR
UNSIGN (1 BYTE)
164
READ (4-20mA) OUTPUT CHANNEL #2 PARAMETERS
D/A SETTING FOR 4mA OUT OUTZ2
UNSIGN (2BYTES)
D/A SETTING FOR 20mA OUT OUTF2
UNSIGN (2BYTES)
CHANNEL #2 OUT VARIABLE CHA_2_PRO_VAR
UNSIGN (1 BYTE)
166
WRITE (4-20mA) OUTPUT CHANNEL #3 PARAMETERS
D/A SETTING FOR 4mA OUT
OUTZ3
UNSIGN (2BYTES)
D/A SETTING FOR 20mA OUT OUTF3
UNSIGN (2BYTES)
CHANNEL #3 OUT VARIABLE CHA_3_PRO_VAR
UNSIGN (1 BYTE)
167
READ (4-20mA) OUTPUT CHANNEL #3 PARAMETERS
D/A SETTING FOR 4mA OUT OUTZ3
UNSIGN (2BYTES)
D/A SETTING FOR 20mA OUT OUTF3
UNSIGN (2BYTES)
CHANNEL #3 OUT VARIABLE CHA_3_PRO_VAR
UNSIGN (1 BYTE)
