ST100 HART Command List
The ST100 HART commands are divided into the three groups.
1. Universal Commands
2. Common Practice Commands
3. Manufacturer Specific Commands.
ST100 HART Universal Commands
The ST100 HART supports Universal Commands 0 through 22. Commands 4 and 5 are reserved under Universal Command
Specification Rev. 7.1 (HCF_SPEC-127, Revision 7.1) and not implemented in this specification. There is no hart command 10.
HART COMM NUMB. HART COMMAND DESCRIPTION HART DATA TYPE & SIZE
0
READ UNIQUE IDENTIFIER -
"254" "254"
UNSIGN (1 BYTE)
EXPANDED DEVICE TYPE EXPAND DEV TYPE
ENUM (2 BYTE)
MINIMUM PREAMBLES - REQUEST MIN # PREAMBLES
UNSIGN (1 BYTE)
HART PROTOCOL MAJOR REV HART PROTOCOL REV.
UNSIGN (1 BYTE)
DEVICE REVISION LEVEL DEV. REV LEVEL
UNSIGN (1 BYTE)
DEVICE SOFTWARE REVISION LEVEL SOFTWARE REV. LEVEL
UNSIGN (1 BYTE)
ELECTRONICS REVISION LEVEL (HARDWARE) ELECTRONICS REV. LEVEL
UNSIGN (1 BYTE)
PHYSICAL SIGNALING CODE STAK SOFT. REV
CODE 0 = BELL 202 CURRENT ENUM (1 BYTE)
FLAGS FLAGS
CODE 01 = MULTI SENSOR ENUM (1 BYTE)
DEVICE ID DEV. ID NUMB.
UNSIGN (3 BYTES)
MINIMUM PREAMBLES - RESPONSE
UNSIGN (1 BYTE)
MAXIMUM # OF VARIBLES MAX # VARIABLES
UNSIGN (1 BYTE)
CONFIGURATION CHANGE COUNTER CONFIG CHANGE COUNT
UNSIGN (2 BYTES)
EXTENDED FIELD DEVICE STATUS
UNSIGN (1 BYTE)
MANUFACTURER ID CODE
FCI CODE = 166 DEC (00A6) ENUM (2 BYTES)
