ST100 Series HART

16

Fluid Components International LLC

HART COMM NUMB.

HART COMMAND DESCRIPTION

HART DATA TYPE & SIZE

145

READ CUSTOMER ENGINEERING UNITS

FLOW UNITS CODE

FLOW CODE

UNSIGN (1 BYTE)

TEMPERATURE UNITS CODE

TEMP CODE

UNSIGN (1 BYTE)

TOTALIZER UNITS CODE

TOTAL CODE

UNSIGN (1 BYTE)

PRESSURE UNITS CODE

PRESS CODE

UNSIGN (1 BYTE)

146

WRITE CUSTOMER ENGINEERING UNITS
FLOW UNITS CODE

FLOW CODE

UNSIGN (1 BYTE)

TEMPERATURE UNITS CODE

TEMP CODE

UNSIGN (1 BYTE)

TOTALIZER UNITS CODE

TOTAL CODE

UNSIGN (1 BYTE)

PRESSURE UNITS CODE (optional)

PRESS CODE

UNSIGN (1 BYTE)

148

READ PLENUM INFORMATION (PIPE SIZE)

PLENUM HEIGHT VALUE

PIPE_HEIGHT

FLOAT (4BYTES)

PLENUM WIDTH (DIAM) VALUE

PIPE_WIDTH

FLOAT (4BYTES)

PLENUM UNITS CODE

PIPE_CODE

UNSIGN (1 BYTE)

149

WRITE PLENUM INFORMATION (PIPE SIZE)

PLENUM HEIGHT VALUE

PIPE_HEIGHT

FLOAT (4BYTES)

PLENUM WIDTH (DIAM) VALUE

PIPE_WIDTH

FLOAT (4BYTES)

PLENUM UNITS CODE

PIPE_CODE

UNSIGN (1 BYTE)

150

WRITE "WRITE PROTECT" MODE

WRITE_PROT

UNSIGN (1 BYTE)
