10 TECHNICAL DATA
Storage case
Dimension (W/H/D) 420/335/280 mm
Hand held terminal
Version A Version C
Dimension (W/H/D) 100/210/45 mm 100/210/45 mm
Measuring range vapor flow 0 to90 litre/min 0 to 90 litre/min
Resoluton vapor flow 0,2 lire/min 0,2 litre/min
0,4 litre/min *
0,4 litre/min **
Resoluton vapor flow
or over 51 litre/min:
0,4 litre/min 0,4 litre/min
Measuring range vapor volume 0 to 99,5 litre 0 to 99,5 litre
Resoluton vapor volume 0,5 litre 0,5 litre
Measuring range fuel flow 0 to 51 litre/min 0 t0 51 litre/min
0 to 80 litre/min **
Resoluton fuel flow 0,2 litre/min 0,2 litre/min
0,4 litre/min *
Adjustable C-factor 100 to 125 % 100 to 125 %
100 to 200 % *
Ambient temperature 0°C to +50°C -10 °C to +50 °C
Printer Interface Centronnics-
Interface
Calibration period every two years every two years
* Ansteuerung mit K-Faktor 200 %
** Ansteuerung mit K-Faktor 80 Liter
