1094_400 - 17
english
There are four basic functions available within the operator modes:
• Actual Values
All the actual measured values (fuel flow, vapor flow, recovery rate, vapor
volume) and the set parameters (times, flow curve points, factors) are
displayed.
• Manual Settings
Parameters (C-factor, times, pulse rate) can be changed.
• Automatic Calibration
The self adaptation is automatically carried out.
• Testing
Fuel flow is simulated and the resulting vapor flow and recovery rate are
displayed.
In the operator modes PRTXXXX (Version C) the vapor recovery system is
tested. At the end of this test a protocol can be printed.
6.5 Basic Functions of the Operator Modes
The access to the basic functions in the operator modes is displayed in the
following schematics.
