Burkert Type 8630 - Manual

Control valve with
TOP Control Continuous
Quickstart Installation and Operation
GENERAL INFORMATION
• Comply with the generally recognised rules of
practice for the application planning and
operation of the device!
• Installation and maintenance work is only to be
carried out by suitably trained tradesmen using
appropriate tools and equipment!
• Comply with the applicable accident prevention
and safety regulations for electrical equipment
during operation and maintenance work on the
device!
• Always switch off the voltage supply prior to any
interventions to the system!
• Remember that pipelines and valves in systems
which are under pressure must not be opened!
• Take appropriate steps to rule out inadvertent
actuation or unacceptable maltreatment!
• Guarantee a defined and controlled system
restart following an interruption to the electrical or
pneumatic supply!
Safety instructions
GENERAL INFORMATION TECHNIC
Technic
The device contains electronic components which react
sensitively to an electrostatic discharge (ESD). Contact with
electrostatically charged persons or objects will damage these
components. In the worst case they are immediately destroyed
or will fail after commissioning.
Comply with the requirements according to EN 100 015 – 1 in
order to minimise or eliminate the possibility of damage
through an abrupt electrostatic discharge. Take care also not
to touch electronic components when the supply voltage is
applied.
ATTENTION EXERCISE CAUTION WHEN
HANDLING!
ELECTROSTATICALLY ENDANGERED
COMPONENTS / ASSEMBLIES
Described in these instructions by way of example, is the
commissioning of a single-acting control valve without field
bus communication.
You will find the detailed description of the device in the
operating instructions for the TOP
Control Continuous Type
8630 also in the operating instructions for the process valves
on the supplied CD.
Use for the intended purpose
Comply with the directions in these instructions, also the
operating conditions and permissible data according to
Datasheet Type 8630, to ensure that the device functions correctly and
remains serviceable throughout its life. In the event of non-
compliance with these instructions, also of impermissible
interventions to the device, we waive all liability and the guarantee for
the device and all accessory parts is cancelled! The device is
intended exclusively for use as a positioning and process control
system. Any different use or use going beyond this is considered
improper use. Bürkert is not liable for damage resulting from such
use. The risk is carried solely by the user.
• Analog
• Inductiv
• Binary i
• Bus com
• Softwar
Possibl
We reserve
Safety instructions
GB
Fluid Control Systems
Operating
Ambient te
Degree of
Electrical
Voltage su
Safety clas
Pneumatic
Control me
- Dust con
- Water co
- Oil conte
Temperatu
of compre
Pressure r
Fluctuation
pressure
