12
Technical data
AC10-5-PD64 0.19 ... 0.005 2.25 -40 ... +50 T6
AC10-5-PD65 0.114 ... 0.003 1.25 -40 ... +60 T6
AC10-6-PD66 0.8 ... 0.02 9 -40 ... +60 T4
AC10-6-PD67 0.31 ... 0.009 3.5 -40 ... +60 T5
AC10-6-PD68 0.16 ... 0.005 1.8 -40 ... +60 T6
AC10-4-PD69 0.35 ... 0.01 4 -40 ... +50 T5
AC10-4-PD70 0.25 ... 0.007 3 -40 ... +60 T5
AC10-4-PD72 0.13 ... 0.003 1.5 -40 ... +60 T6
6.5.2. Coils for individual or battery
assembly
DANGER!
Risk of explosion due to overheating!
In the case of battery assembly observe the following data of the
valves:
• Dimension of the valve body: 32 mm x 32 mm x 10 mm.
• Material of the valve body: Brass (MS), aluminium (AL), stainless
steel (VA) or plastic (PA 6 GV).
Universal current, nominal voltage 12 ... 400 V, frequency 0 ... 60 Hz
Coil type Rated current
[A]
Power
limit
[W]
Max. per-
mitted
ambient
temperature
[°C]
Tempe-
rature
class
1)
AC10-5-PD73 0.68 ... 0.02 7 -30 ... +40 T4 1
AC10-5-PD74 0.25 ... 0.007 3 -30 ... +50 T5 1
AC10-5-PD75 0.19 ... 0.005 2.25 -30 ... +40 T6 1
AC10-5-PD76 0.114 ... 0.003 1.25 -30 ... +60 T6 1
AC10-4-PD77 0.33 ... 0.01 4 -30 ... +40 T5 5
AC10-4-PD78 0.25 ... 0.007 3 -30 ... +50 T6 5
AC10-4-PD79 0.13 ... 0.003 1.5 -30 ... +55 T6 5
AC10-5-PD80 0.68 ... 0.02 7 -40 ... +40 T4 1
AC10-5-PD81 0.25 ... 0.007 3 -40 ... +50 T5 1
AC10-5-PD82 0.19 ... 0.005 2.25 -40 ... +40 T6 1
AC10-5-PD83 0.114 ... 0.003 1.25 -40 ... +60 T6 1
AC10-4-PD84 0.33 ... 0.01 4 -40 ... +40 T5 5
AC10-4-PD85 0.25 ... 0.007 3 -40 ... +50 T5 5
AC10-4-PD86 0.13 ... 0.003 1.5 -40 ... +55 T6 5
1) In the case of battery assembly: min. distance from the wall [mm]
english
PTB 00 ATEX 2129 X
