Table 4-3 Delta Class EL Series Models SLA5850 & SLA5860 Standard Restrictors.
Size
A
Restrictor size selected from the table below is based on sensor Nitrogen equivalent flow
Plug (Nitrogen equivalent flows of 8.022 SCCM or less) Part Number Part Number Part Number
Models SLA5850 / SLA5860
Min. Flow Max. Flow Sintered ACLFE Wire Mesh
(SCCM Nitrogen equivalent flow at 0° C)
B -----
C Plug (Nitrogen flows <= 8.022 SCCM) 618K019BMT
D 8.022 11.36 S110Z296BMA S110Z275BMT
E 11.23 15.90 S110Z297BMA S110Z276BMT
F 15.72 22.26 S110Z298BMA S110Z277BMT
G 22.01 31.17 S110Z299BMA S110Z278BMT
H 30.82 43.64 S110Z300BMA S110Z279BMT
J 43.14 61.09 S110Z301BMA S110Z280BMT
K 60.40 85.53 S110Z302BMA S110Z281BMT
L 84.56 119.7 S110Z303BMA S110Z282BMT
M 118.4 167.6 S110Z304BMA S110Z283BMT
N 165.7 234.7 S110Z305BMA S110Z284BMT
P 232.0 328.6 S110Z306BMA S110Z285BMT
Q 324.8 460.0 S110Z307BMA S110Z286BMT
R 454.8 644.0 S110Z308BMA S110Z287BMT
S 636.7 901.6 S110Z309BMA S110Z288BMT
T 891.4 1262 S110Z310BMA S110Z289BMT
U 1248 1767 S110Z311BMA S110Z290BMT
V 1747 2474 S110Z312BMA S110Z291BMT
W 2446 3464 S110Z313BMA S110Z292BMT
X 3424 4849 S110Z319BMA
Y 4794 6789 S110Z321BMA
1 6711 9504 S110Z317BMA
2 9369 13310 S110Z228BMA
3 13150 18630 S110Z226BMA
4 18420 30000 S110Z224BMA
NOTES: 1) If two sizes are allowed because of overlap, select the larger size.
2) If customer has requested a calibration based on a 21.1'C (70'F) reference
temperature, divide the air equivalent flow rate by 1.077 before using the sizing table.
No Restrictor ( ALL BODY SIZES)
