3. Determine Critical Pressure Drop
Critical pressure drop occurs when the outlet pressure (psia) is less than
half the inlet pressure (psia) or
P outlet <
If these conditions exist, the pressure drop (Dp) should be calculated as
follows:
Dp =
Dp = Pressure drop (psi)
P
in
= Inlet pressure (psia)
If these conditions do not exist, pressure drop equals the inlet pressure
minus the outlet pressure.
Is 44.7 psia < ? — No.
Then Dp = 64.7 - 44.7 = 20 psi
4. Using the nomograph, locate the pressure drop (psi) on the vertical line
marked "Dp" (Point A).
5. Locate the Nitrogen equivalent flow rate (sccm Nitrogen) on the vertical
marked "Q
NITROGEN
" (Point B).
6. Draw a line connecting Dp and Q
NITROGEN
and extend it to the baseline.
Mark this point (Point C).
7. Locate inlet pressure (psia) on the vertical line marked "P
in
" (Point D).
8. Draw a line connecting P
in
(Point D) and baseline (Point C) and then
extend this line to the vertical line marked D
o
(orifice diameter, inches)
(Point E).
9. This point on the line is the minimum orifice size for the given conditions.
If this point is between two orifice sizes, select the next largest size orifice
to ensure adequate flow. If the orifice selected falls below .0013, choose
.0013 size orifice.
For the example in Figure 4-3, the .007 size orifice would be selected.4-5
Restrictor Sizing
64.7 psia
2
P
in
2
P inlet
2
