Section 1 Introduction
SolidSense II
®
Series
Installation and Operation Manual
X-PR-SolidSense II-PT-eng
Part Number: 541B160AAG
July, 2011
Sample Model Code
I
II
III
IV V VI VII
GF
F
02
C
4 P SF
1-4 Product Description Code
The following Product Description Code (PDC) identifies the SolidSense II
pressure transducer in various configurations. This code is used to order
your SolidSense II pressure transducer. Call your Brooks Service and
Support Representative if you need assistance.
Code Description
Code Option
Option Description
I.
Base Model Code
GF
Pressure Transducer
II.
Body Type
D
Dead End
F
Flow Through
III.
PSI
00
30
01
100
02
250
05
300
10
1000
25
2500
30
3000
IV.
Pressure Reference
A
Absolute
C
Compound
G
Gauge
V.
Output
3
0.00 to 10.00 Vdc
4
4 to 20 mA
5
0.05 to 5.05 Vdc
VI.
Electrical Connection
P
6’ (2m) Pigtial
M
5” (0.127m) Pigtail
VII.Fittings
4S
Tube Stub 1/4” O.D. (GFD Only)
CS
Surface Mount, 1.125” C-Seal, Standard (GFD Only)
CH
Surface Mount, 1.5” High Flow K1H (GFD Only)
SC
Surface Mount, 1.5” C-Seal (GFD Only)
5W
Surface Mount, 1.5” W-Seal (GFD Only)
4W
Surface Mount, 1.125” W-Seal (GFD Only)
VM/VCR
Face Seal, fixed male (x2 on Duncan T for GFF)
VS
Face Seal, fixed male/swivel female on Duncan T (GFF Only)
SM
Face Seal, swivel male (x2 on Duncan T for GFF)
SF
Face Seal, swivel female (x2 on Duncan T for GFF)
4T
Duncan T, 1/4” Tube Stub (GFF Only)
3T
Duncan T, 3/8” Tube Stub (GFF Only)
3M
Duncan T, 3/8” with Face Seal, swivel male (GFF Only)
2T
Duncan T, 1/2” Tube Stub (GFF Only)
