Figure 1-2C SolidSense II Pressure Transducer Dimensions for Dead-End with DB15, Bendix and Pigtail Connections
NO. 4
VCR SWIVEL FEMALE PIGTAIL
GFDXXXXPSF
FITTING A333124002
ME131190
PIGTAIL
.84 [21.33]
3.40 [86.36]
W-SEAL BENDIX
GFDXXXXBWS
GFDXXXXB5W
FITTING A333366001
BENDIX
.84 [21.33]
1.53 [38.97]
3.74 [95.10]
W-SEAL BENDIX
GFDXXXXPWS
GFDXXXXP5W
FITTING A333366001
PIGTAIL
1.53 [38.97]
3.80 [96.52]
.84 [21.33]
BENDIX
1.5" C-SEAL BENDIX
GFDXXXXB5SC
FITTING A333367001
.84 [21.33]
1.48 [37.59]
3.45 [87.67]
PIGTAIL
NO. 4
VCR SWIVEL MALE PIGTAIL
GFDXXXXPSM
FITTING A333124001
ME131193
.84 [21.33]
4.00 [101.6]
1.5" C-SEAL DB15
GFDXXXD5SC
FITTING A333367001
DB15 .84 [21.33]
2.97 [75.40]
1.48 [37.59]
1 1/8" C-SEAL W/AMP ON PIGTAIL
GFDXXXXMCS
FITTING A333127001
CABLE A333110004
.84 [21.33]
1.12 [28.57]
3.42 [86.90]
PIGTAIL
VCR SWIVEL FEMALE
W/AMP 5" PIGTAIL
GFDXXXXMSF
CABLE A333110004
FITTING A333124002
ME131190
PIGTAIL
.84 [21.33]
3.40 [86.36]
PIGTAIL
VCR SWIVEL MALE 3 METER PIGTAIL
GFDXXXXSSM
CABLE A333110003
FITTING A333124001
ME131193
.84 [21.33]
4.00 [101.6]
VCR SWIVEL MALE PIGTAIL
GFDXXXXPSMA
FITTING A333124001
ME131193
3.59 [91.19]
1.06 [26.92]
4.26 [108.10]
PIGTAIL
VCR SWIVEL FEMALE PIGTAIL
GFDXXXXPSFA
FITTING A333124002
ME131190
3.00 [76.20]
1.06 [26.92]
3.67 [93.11]
PIGTAIL
1 1/2" C-SEAL PIGTAIL 9"
TO 15 PIN D-SUB
GFDXXX3ECH
FITTING 220-32832-000
CABLE 215-31423-000
3.93 [99.82]
1.49 [37.85]
.84 [21.33]
PIGTAIL
