SolidSense II ® Series
1-5 SolidSense II Pressure Transducer Specifications
Category Operating Guidelines
Electrical
Supply Current Max. 10 mA for 0.00 Vdc and 0.05 to 5.05 Vdc Output
Power Requirement
10 to 30 Vdc for 4 to 20 mA Output
11 to 30 Vdc for 0.05 to 5.05 Output
13 to 32 Vdc for 0.00 to 10.00 Output
Connections 4-Pin Bendix connector
6 ft. (2m) Pigtail (24 AWG shielded cable)
15-Pin D-Sub HD male connection
Protection Reverse polarity for power connections
Mechanical
Housing Stainless Steel, Polymer Plastics
Proof Pressure 200% of ful scale (F.S.) up to 1000 PSI
150% of F.S. for higher ranges
Burst Pressure 400% of F.S.
Wetted Parts 316L Stainless Steel, SEMI F20
Surface Finish Compliant to SEMI F19, 5 Ra Standard
Cleanliness Compliant to ASTM F1374-92 (2005)
Internal Volume 1.79 cc
Process Connection Refer to PDC (paragraph 1-2) for options
Shipping Weight (approximate) 0.70 lbs. (0.32 kg)
Accuracy +0.25% BFSL (Linearity, Hysterisis and Repeatability)
Response Time < 5 msec
Thermal Zero and Span Shift (each) > 100 PSI Range F.S.
+0.02% F.S./
O
F (-4
O
to 140
O
F, -20
O
to 60
O
C)
+0.05% F.S. ( -20
O
to 60
O
C) for 0-10 Vdc version
< 100 PSI Range F.S.
+0.04% F.S./
O
F (-4
O
to 140
O
F, -20
O
to 60
O
C)
+1.0% F.S. (20
O
to 60
O
FC) for 0-10 Vdc version
Temperature
Storage: -20
O
to 180
O
F (-29
O
to 82
O
C)
Compensated: -4
O
to 140
O
F, (-20
O
to 60
O
C)
Compensated: 20 O to 140 O F (20 O to 60 O C) for 0-10 Vdc version
FM Approved Non-Incendive for use in Class 1, Div 2, Groups A, B, C and D
Excludes 0-10 Vdc and 15-Pin D Sub HD male connection
CE Compliant to EMC Directive EN61326
RoHS Compliant to EU Directive 2002/95/EC
ATEX* Compliant to EU Directive 94/9/EC
Certifications
Performance
*SolidSense II ATEX Pressure Transmitter Only
