Brooks Instrument SolidSense II - Manual (Page 12)

1-6
Section 1 Introduction Installation and Operation Manual
X-PR-SolidSense II-PT-eng
Part Number: 541B1560AAG
July, 2011
SolidSense II ® Series
Figure 1-2B SolidSense II Pressure Transducer Dimensions for Thru-Tubes/Dead-End with DB15, Bendix and Pigtail
Connections
1.125" W-SEAL BENDIX
GFDXXXXB4W
FITTING A333446001
BENDIX
.84 [21.33]
1.122 [28.5]
3.52 [89.4]
PIGTAIL
1 1/8" C-SEAL PIGTAIL
GFDXXXXPCS
FITTING A333127001
.84 [21.33]
1.12 [28.57]
3.42 [86.90]
VCR SWIVEL MALE BENDIX
GFDXXXXBSM
FITTING A333124001
BENDIX
NO. 4
.84 [21.33]
3.89 [98.84]
1 1/8" C-SEAL DB15
GFDXXXXDCS
FITTING A333127001
DB15
1.12 [28.57]
.84 [21.33]
2.92 [74.13]
VCR SWIVEL FEMALE BENDIX
GFDXXXXBSF
FITTING A333124002
ME131190
NO. 4
BENDIX
.84 [21.33]
3.30 [83.86]
TUBE STUB/TUBE STUB
THRUTUBE PIGTAIL
GFFXXXXP4TA
FITTING A333125001
2.94 [74.62]
1.06 [26.92]
.31 [7.92]
.25 [6.35]
1.85 [46.98]
.42 [10.79]
3.60 [91.54]
PIGTAIL
TUBE STUB/TUBE STUB
THRUTUBE PIGTAIL
GFFXXXXP3T
FITTING A333125002
1.85 [46.98]
.84 [21.33]
3.36 [85.40]
.31 [7.92]
2X .42 [10.79]
2X .37 [9.52]
PIGTAIL BENDIX
TUBE STUB/TUBE STUB
THRUTUBE BENDIX
GFFXXXXB3T
FITTING A333125002
.84 [21.33]
1.85 [46.98]
2.82 [71.62]
.31 [7.92]
2X .42 [10.79]
2X .37 [9.52]
VCR SWIVEL MALE
THRUTUBE PIGTAIL
GFFXXXXP3M
FITTINGS A333125002
2 - 132-31109-000,
2 - A332396001
.84 [21.33]
5.55 [140.97]
3.36 [85.40]
PIGTAIL
VCR SWIVEL MALE
THRUTUBE BENDIX
GFFXXXXB3M
FITTINGS A333125002
2 - 132-31109-000,
2 - A332396001
.84 [21.33]
2.82 [71.62]
5.55 [140.97]
BENDIX
TUBE STUB/TUBE STUB
THRUTUBE PIGTAIL
GFFXXXXP2T
FITTING A333125003
1.85 [46.98]
.84 [21.33]
3.36 [85.40]
.31 [7.92]
2X .42 [10.79]
2X .50 [12.70]
PIGTAIL
TUBE STUB/TUBE STUB
THRUTUBE BENDIX
GFFXXXXB2T
FITTING A333125003
.84 [21.33]
1.85 [46.98]
2.82 [71.62]
.31 [7.92]
2X .42 [10.79]
2X .50 [12.70]
BENDIX
