Brooks Instrument SolidSense II - Manual (Page 11)

1-5
Section 1 Introduction
SolidSense II ® Series
Installation and Operation Manual
X-PR-SolidSense II-PT-eng
Part Number: 541B160AAG
July, 2011
Figure 1-2A SolidSense II Pressure Transducer Dimensions for Thru-Tubes with DB15, Bendix and Pigtail Connections
BENDIX
VCR FIXED MALE
THRUTUBE BENDIX
GFFXXXBVM
FITTING A333125004
2.24 [56.90]
.84 [21.33]
3.28 [83.23]
DB15
VCR SWIVEL FEMALE
THRUTUBE DB15
GFFXXXDSF FITTING A333125001
2 - ME131131,
2-ME0136103004
2.96 [75.17]
2.78 [70.64]
.84 [21.33]
VCR SWIVEL MALE
THRUTUBE PIGTAIL
GFFXXXXPSM FITTINGS A333125001
2 - ME131122,
2 - ME0136103003
PIGTAIL
.84 [21.33]
4.035[102.5]
3.36 [85.40]
PIGTAIL
VCR FIXED MALE/
VCR SWIVEL FEMALE
THRUTUBE PIGTAIL
GFFXXXXPVS FITTING A333125005
ME131131,
ME0136103004
.84 [21.33]
3.36 [85.40]
2.60 [66.04]
BENDIX
.84 [21.33]
VCR FIXED MALE/
VCR SWIVEL FEMALE
THRUTUBE BENDIX
GFFXXXXBVS FITTING A333125005
ME131131,
ME0136103004
2.60 [66.04]
3.26 [82.90]
PIGTAIL
.84 [21.33]
VCR FIXED MALE
THRUTUBE PIGTAIL
GFFXXXXPVM
FITTING A333125004
2.24 [56.90]
3.36 [85.40]
PIGTAIL
.84 [21.33]
VCR SWIVEL FEMALE
THRUTUBE PIGTAIL
GFFXXXXPSF FITTING A333125001
2 - ME131131,
2 - ME0136103004
2.96 [75.17]
3.36 [85.40]
TUBE STUB/TUBE STUB
THRUTUBE PIGTAIL
GFFXXXXP4T
FITTING A333125001
PIGTAIL
1.85 [46.98]
.84 [21.33]
3.36 [85.40]
.31 [7.92]
2X .42 [10.79]
2X .25 [6.35]
BENDIX
TUBE STUB/TUBE STUB
THRUTUBE BENDIX
GFFXXXB4T
FITTING A333125001
.84 [21.33]
1.85 [46.98]
2.82 [71.62]
.31 [7.92]
2X .42 [10.79]
2X .25 [6.35]
VCR SWIVEL FEMALE
THRUTUBE BENDIX
GFFXXXBSF FITTING A333125001
2 - ME131131,
2 - ME0136103004
.84 [21.33]
BENDIX
2.96 [75.17]
3.26 [82.90]
BENDIX
VCR FIXED MALE
THRUTUBE BENDIX
GFFXXXJVM
BENDIX PINS
B & D JUMPERED
FITTING A333125004
2.24 [56.90]
.84 [21.33]
3.28 [83.23]
TUBE STUB/TUBE STUB
THRUTUBE BENDIX
GFFXXXB4TA
FITTING A333125001
2.89 [73.40]
1.06 [26.92]
.31 [7.92]
.25 [6.35]
1.85 [46.98]
.42 [10.79]
BENDIX
