X85 Pallet
Spare parts
Standard Des. Manufacturer Type Order FlexLink ID
name number
Pallet 160x125 mm
Sensor B1 SICK IM12-08NPS-ZC1 7900045 5058572
Sensor bracket FlexLink XBPB 12 H 5110793
Sensor B2 SICK IQ10-06NPS-KT1 7900209 5058574
Sensor B3 SICK IM08-02BPS-ZT1 7900005 5110130
Sensor B4 SICK IM12-08NPS-ZC1 7900045 5058572
Sensor B5 SICK IM12-08NPS-ZC1 7900045 5058572
RFID Reader/Writer B10 IFM DTA100 5058152
Read/Write head bracket FlexLink 5110840
Pallet 160x175 mm
Sensor B1 SICK IM12-08NPS-ZC1 7900045 5058572
Sensor bracket FlexLink XBPB 12 H 5110793
Sensor B2 SICK IM12-08NPS-ZC1 7900045 5058572
Sensor bracket FlexLink XBPB 12 H
Sensor B3 SICK IM08-02BPS-ZT1 7900005 5110130
Sensor B4 SICK IM12-08NPS-ZC1 7900045 5058572
Sensor B5 SICK IM12-08NPS-ZC1 7900045 5058572
RFID Reader/Writer B10 IFM DTA100 5058152
Read/Write head bracket FlexLink 5110840
Pallet 160x225 mm
Sensor B1 SICK IM12-08NPS-ZC1 7900045 5058572
Sensor bracket FlexLink XBPB 12 H 5110793
Sensor B2 SICK IM12-08NPS-ZC1 7900045 5058572
Sensor bracket FlexLink XBPB 12 H 5110793
Sensor B3 SICK IM08-02BPS-ZT1 7900005 5110130
Sensor B4 SICK IM12-08NPS-ZC1 7900045 5058572
Sensor B5 SICK IM12-08NPS-ZC1 7900045 5058572
RFID Reader/Writer B10 IFM DTA100 5058152
Read/Write head bracket FlexLink 5110840
