X85 Pallet

Initiators

B1: M12-connector, 3-pin
B2: M12-connector, 3-pin
B3: M12-connector, 3-pin
B4: M12-connector, 3-pin
B5: M12-connector, 3-pin

B10: M12-connector, 4-pin (Asi)

Note: Sensors placed inside the Locating housing are
equipped with sensor cables (with the given connector
type above), reaching outside the housing.

Actuators

Pneumatic cylinders

A1: 6 mm
A2: 6 mm
A3: 6 mm (tubing)
A4: 6 mm

Note: The A3 cylinder, placed inside the Locating housing,
is equipped with tubes (with the given size above),
reaching outside the housing.

Interfaces
