X85 pallet – FlexLink X85 Туннельный модуль XBUL 11T Руководство пользователя User Manual

Page 5

background image

X85 Pallet

Initiator cable connector type

B1: M12-connector, 3-pin
B2: M12-connector, 3-pin
B3: M12-connector, 3-pin
B4: M12-connector, 3-pin

B10: M12-connector, 3-pin (AS-i)

Note: Sensors placed inside the housing is equipped with
sensor cables (with the given connector type above),
reaching outside the housing.

Actuator tubing size

Pneumatic cylinders

A1: 6 mm
A2: 6 mm
A3: 6 mm

Interfaces
