Connections and Setup | 3

17

Workstation Series User’s Guide

Control Panel

The control panel consists of the two (2) main buttons on the printer cover, two (2) LEDs
on the printer cover and the reset button on the back of the printer. All three are used to
perform certain printer functions.

LEDs

The green and red LEDs may blink during the operation of the printer. There are
functions of the printer where the blinking lights can be used to interpret the printer’s
state.

A slow blink is considered a repeating blink that lights for 0.8 seconds and then turns
off for 0.8 seconds. This sequence will repeat until the task has been completed.

A fast blink is considered a repeating blink that lights for 0.1 seconds and then turns
off for 0.1 seconds. This sequence will repeat until the task has been completed.

A double blink is considered two fast blinks with a pause in between.

More information is presented in the troubleshooting section.

LED Indicators

The LEDs are used to indicate the printer’s state.

Table 2: LED Chart

Light

Printer State

Green

Fast Blink - Waiting for an operator action

Slow Blink - Printer is processing data

Solid Light - Printer ready state

Fast Blink with Pause - Configuration Utility Control Mode

Red

Fast Blink - Hardware Error

Slow Blink - Warning

Solid Light - Fault

Fast Blink with Pause - Maintenance Timer Expired

Green/Red
Combination

Fast Alternating Blink - Recovery Mode

Slow Alternating Blink - Upgrade in Progress

Slow Synchronized Blink - Cooling Down

Synchronized Double Blink - Power-up in Progress
